Goodrive350-19 series VFD Dimensional drawings
-503-
W1
D1
W2 W2
D2
H2H1
W4
W3
W2
W2
H4
H2
H3
Figure C.20 660V 160–220kW VFD flange installation diagram
VFD model
Outline
dimensions
(mm)
Mount
dimensions
(mm)
Hole distance
(mm)
Hole
diameter
(mm)
Screw
Net
weight
(kg)
Gross
weight
(kg)
W1
H1
D1
W2
H2
D2
W3
H3
W4
H4
160kW–220kW
500
870
358
180
850
178.5
480
796
60
37
11
M10
85
110
C.6.3 Floor installation dimensions
W4
W2
W2
H1
H2
D1
W1
W3
D2
D2
3- ø13.0
6- ø12.0
Figure C.21 660V 250–355kW VFD floor installation diagram
VFD model
Outline dimensions
(mm)
Mount dimensions
(mm)
Hole
diameter
(mm)
Screw
Net
weight
(kg)
Gross
weight
(kg)
W1
H1
D1
W4
W2
W3
H2
D2
250kW–355kW
750
1410
380
680
230
714
1390
150
13/12
M12/M10
135
165
