INVT Goodrive350-19 Series

Goodrive350-19 series VFD Dimensional drawings
-502-
W1
W2
D1
H1 H2
6- ø13.0
W2
Figure C.18 660V 250–355kW VFD wall-mounting diagram
VFD model
Outline dimensions
(mm)
Mount
dimensions
(mm)
Hole
diameter
(mm)
Screw
Net
weight
(kg)
Gross
weight
(kg)
W1
H1
D1
W2
H2
250kW–355kW
680
960
380
230
926
13
M12
135
165
C.6.2 Flange installation dimensions
W1
H1
D1
W2
H2
98.0
D2
W2
W3W4
H4
H2
H3
Figure C.19 660V 22–132kW VFD flange installation diagram
VFD model
Outline
dimensions
(mm)
Mount
dimensions
(mm)
Hole distance
(mm)
Hole
diameter
(mm)
Screw
Net
weight
(kg)
Gross
weight
(kg)
W1
H1
D1
W2
H2
D2
W3
H3
W4
H4
22kW–45kW
270
555
325
130
540
167
261
516
65.5
17
7
M6
30
32
55kW–132kW
325
680
363
200
661
182
317
626
58.5
23
9.5
M8
47
67
