INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Commissioning
- 45 -
Function
code
Name
Setting
Remarks
detection level
P11.14
Speed deviation detection
value
20.0%
P11.15
Speed deviation detection
time
2.0s
Speed deviation protection can be
performed.
P25.01
Function of S5 terminal
7
Fault reset
P25.02
Function of S6 terminal
75
Brake feedback signal
P90.04
Enabling brake-oriented
logic
1
The brake is controlled by the VFD.
P90.06
Graded multi-step speed
reference 0
10.0%
Corresponding to the max. frequency
P90.07
Graded multi-step speed
reference 1
30.0%
Corresponding to the max. frequency
P90.08
Graded multi-step speed
reference 2
50.0%
Corresponding to the max. frequency
P90.09
Graded multi-step speed
reference 3
70.0%
Corresponding to the max. frequency
P90.10
Graded multi-step speed
reference 4
90.0%
Corresponding to the max. frequency
P90.14
Forward brake release
torque
50.0%
Corresponding to the motor rated torque
P90.15
Reverse brake release
torque
30.0%
Corresponding to the motor rated torque
P90.16
Forward brake release
frequency
0.20Hz
P90.17
Reverse brake release
frequency
0.20Hz
P90.18
Forward brake closing
frequency
0.50Hz
P90.19
Reverse brake closing
frequency
1.00Hz
P90.20
Delay before forward
brake release
0.000s
P90.22
Delay after forward brake
release
0.500s
P90.24
Delay before forward
brake closing
0.000s
