INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Commissioning
- 92 -
User-
defined
function
list
Related
function
code
Name
Description
Setting
range
Default
forward-running direction.)
A80.26
P90.06
Graded multi-step
speed reference 0
0.0–100.0%
0.0–100.0
0.0%
A80.27
P90.07
Graded multi-step
speed reference 1
0.0–100.0%
0.0–100.0
0.0%
A80.28
P90.08
Graded multi-step
speed reference 2
0.0–100.0%
0.0–100.0
0.0%
A80.29
P90.09
Graded multi-step
speed reference 3
0.0–100.0%
0.0–100.0
0.0%
A80.30
P90.10
Graded multi-step
speed reference 4
0.0–100.0%
0.0–100.0
0.0%
A80.31
P90.12
Forward brake
release current
0.0–200.0% (of the motor
rated current)
0.0–200.0
0.0%
A80.32
P90.13
Reverse brake
release current
0.0–200.0% (of the motor
rated current)
0.0–200.0
0.0%
A80.33
P90.16
Forward brake
release frequency
0.00–20.00Hz
0.00–20.00
3.00Hz
A80.34
P90.17
Reverse brake
release frequency
0.00–20.00Hz
0.00–20.00
3.00Hz
A80.35
P90.18
Forward brake
closing frequency
0.00–20.00Hz
0.00–20.00
3.00Hz
A80.36
P90.19
Reverse brake
closing frequency
0.00–20.00Hz
0.00–20.00
3.00Hz
A80.37
P90.20
Delay before forward
brake release
0.000–5.000s
0.000–5.000
0.300s
A80.38
P90.22
Delay after forward
brake release
0.000–5.000s
0.000–5.000
0.300s
A80.39
P90.24
Delay before forward
brake closing
0.000–5.000s
0.000–5.000
0.300s
A80.40
P90.26
Delay after forward
brake closing
0.000–5.000s
0.000–5.000
0.300s
A80.41
P90.31
Enabling the
monitoring on brake
status
0–1
0: Disable
1: Enable (brake feedback
detection)
0–1
0
