INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Commissioning
- 91 -
User-
defined
function
list
Related
function
code
Name
Description
Setting
range
Default
A80.19
P10.06
Multi-step speed 2
0.0–100.0%
0.0–100.0
0.0%
A80.20
P10.08
Multi-step speed 3
0.0–100.0%
0.0–100.0
0.0%
A80.21
P10.10
Multi-step speed 4
0.0–100.0%
0.0–100.0
0.0%
A80.22
P25.01
Function of S5
terminal
Same as group P05.
0–89
0
A80.23
P25.02
Function of S6
terminal
0–89
0
A80.24
P90.04
Enabling
brake-oriented logic
0–1
0: The brake is controlled by
an external controller.
1: The brake is controlled by
the VFD.
0–1
0
A80.25
P90.05
Enabling forward
torque for
reverse-running
start/stop
0x00–0x11
Ones place: indicates
whether to enable forward
torque for reverse-running
start
0: Disable
(The reverse-running start
direction complies with the
command.)
1: Enable
(The reverse-running start
direction is always the
forward-running direction.)
Tens place: indicates
whether to enable forward
torque for reverse-running
stop
0: Disable
(The reverse-running stop
direction complies with the
command.)
1: Enable
(The reverse-running stop
direction is always the
0x00–0x11
0x00
