iMars series PV energy storage inverter Installation
21
Select installation site according to below requirements:
(1) The height of the installation position should ensure that the line of sight is on the same
level as the LCD for viewing the parameters inverter conveniently.
(2) The installation site must be well ventilated and away from raindrops or direct sunlight.
(3) There must be enough pre-reserved space around the installation site for convenient
disassemble of the inverter and air convection, as shown in Fig 3.4.
(4) The ambient temperature of installation should be -10°C~40°C.
(5) The installation site should be away from electronic devices which can generate strong
electromagnetic interference.
(6) The inverter should be installed on firm and solid surface such as wall surface and metal
bracket.
(7) The installation surface should be vertical to the horizontal line, as shown in Figure 4.21.
