INVT iMars Series User Manual

iMars series PV energy storage inverter Technical parameter
50
9 Technical parameter
Model
iMars-BD3KTL
iMars-BD5KTL
PV DC input parameter (PV side)
Max. input power
3300W
6600W
Max. input voltage
500VDC
Start voltage/min. working voltage
100V/80V
MPPT voltage range
120~450V
Number of MPPT / Strings per MPPT
1/1
2/1
Max. input current
13A
13A×2
Maximum Input Short Circuit Current
15.6A
15.6A×2
Maximum backfeed current to PV array
0A
Grid output parameter (ACside)
Rated AC output power
3000W
4600W
Max. AC output current
13A
20A
Maximum output short circuit current
20A
30A
Maximum output overcurrent protection
20A
30A
Rated grid voltage/grid voltage range
230Vac/180-270Vac
Rated grid frequency/frequency range
50Hz(45~54Hz) / 60Hz(55~65Hz).
AC output type
Single phase (L、N、PE)
Power factor
≥0.99 (±0.95 adjustable)
THDi
≤3%(rated power)
Off-grid parameter
Rated output voltage
220Vac/230Vac/240Vac
Frequency
50Hz/60Hz
Max. output power
3000VA/3000W
4600VA/4600W
Time of switching between grid-connected
and off-grid
20ms
THDv
≤3%(rated power)
Maximum output short circuit current
20A
30A
Maximum output power/time
150%/10S
Allowable reverse current
0A
