Digital488/32/OEM Specifications
WARNING
Do not use this interface outdoors. The interface is intended for indoor use only.
Outdoor conditions could result in equipment failure, bodily injury, or death.
CAUTION
Never disassemble the interface case while it is connected to the AC power line.
Internal voltage potentials exist which could cause bodily injury or death.
Digital I/O
Configuration:
Four 8-bit ports, programmable as inputs or outputs.
Transistor-Transistor Logic (TTL) Levels:
Outputs will drive 2 TTL loads.
Connector:
One 40 pin header, organized as two rows of 20 pins.
IEEE 488
Implementation:
SH1, AH1, T6, TE0, L4, LE0, SR1, RL0, PP0, DC1, DT1, C0, E1.
Terminators:
Selectable CR, LF, LF-CR, and CR-LF with EOI.
Programmable:
IEEE Terminators, EOI, SRQ Mask, Port Data, Active Levels, Handshake Lines, Format and
Configuration.
Connector:
Standard IEEE 488 connector with metric studs.
1-4, Introduction 11-28-01 Digital488 User’s Manual
