nanoLTE S60 AP Hardware Installation nanoLTE AP and PSU Regulatory Information
NANO_INST_43315 v200_0.5 for N4G_2.0 © ip.access Limited 2017 Page 20
5.3 Regulatory Statements for PSAA20R-120L6 PSU
Safety Approvals UL/cUL 60950-1
CB
CE
SAA+C-TICK+MEPS
Mechanical Characteristics L x W x H:
71.7mm x 50.0mm x 39.1mm (2.82" x 1.97" x 1.54")
Weight::
180.8g (6.38oz)
AC Input Voltage Rating 100 to 240V AC
Emissions FCC Class B
EN55022 Class B
AC Input Voltage Range 90 to 264V AC
Immunity IEC61000-4-2 Level 4
IEC61000-4-3 Level 2
IEC61000-4-4 Level 2
IEC61000-4-5 Level 2
IEC61000-4-6 Level 2
IEC61000-4-8 Level 1
IEC61000-4-11
AC Input Frequency 47 to 63Hz
Input Current 0.8A (RMS) maximum at 120V AC and max load
0.5A (RMS) maximum at 240V AC and max load
Leakage Current 0.25mA maximum
Inrush Current <60A for 100V AC at maximum load
<100A for 240V AC at maximum load
(Cold start at ambient 25°C)
Over-Current Protection Short circuit: Auto restart
Short-Circuit Protection Output can be shorted permanently without damage
Input Power Saving 0.1W maximum at no load
Dielectric Withstand (Hi-pot) Test Primary to Secondary: 3000VAC or 4242VDC, 10mA
1min. 3600VAC or 5090VDC, 10mA 3s.
Output Efficiency DOE Level VI
Insulation Class II Double Insulated
Environmental Operation: 0 to +40C
Non-operation: -20 to +75C
Humidity: 20 to 90%
DC Output Connector 5.5mm O.D., 2.1mm I.D., 9.5mm length. Centre
conductor positive.
