iPower AP10000E - Parts List

Page 24
Parts List
NO.
1
2
3
4
5
6
7
8
9
10
10-1
10-2
10-3
10-4
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
Qty.
4
1
1
5
1
1
1
4
2
1
1
1
1
1
2
2
2
1
1
6
1
1
1
1
1
2
2
2
1
1
1
11
6
4
1
2
0.18
1
1
Part Number
30101-00326-00
33082-00171-00
20044-00104-00
30101-00329-00
30101-00113-00
30136-00016-00
33085-00058-00
30101-00090-00
30100-00033-00
20029-10551-00
/
/
/
/
30136-00012-00
30139-00005-00
30128-00008-00
20260-02343-03
33499-00016-00
30125-00019-00
34032-00017-00
30101-00387-00
30101-00361-00
20249-00082-00
20202-00352-00
33048-00093-00
30139-00036-00
30121-00007-00
33138-00009-00
33138-00017-00
20184-00007-00
30101-00339-00
30101-00407-00
30136-00074-00
20130-00451-00
34024-00002-00
34023-00004-00
20133-00002-00
20114-03797-00
Description
Hexagon flange bolt M5*12
Alternator tail cover
Regulator
Hex flange bolt M5*16
Hexagon flange bolt M10*310
Flat Washers
Alternator bracket
Hexagon flange bolt M6*200
Hexagon head bolt M5*225
Rotor-stator assembly
Stator
Rotor
Terminal
Carbon brush
Flat Washers
Spring washer
Nylon nut M5
Engine assembly
Air filter bracket
Hexagon flange nut M6
bushing
Hexagon flange bolt M8*32
Hexagon flange bolt M8*25
Supporting parts
Muffler
Muffler gasket
Spring washer
Hex nut M8
Crankcase cover baffle
Dustproof rubber
Wire shield
Hex flange bolt M6*12
Hexagon flange bolt M6*25
Fuel tank gasket
Fuel tank assembly
Clamp
Fuel pipe
Fuel valve
Control panel assembly
NO.
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
Qty.
4
2
1
1
6
1
1
1
1
1
1
1
1
2
2
1
1
2
1
2
4
2
2
2
2
2
1
1
1
Part Number
30125-00026-00
34030-00040-00
34030-00039-00
34030-00044-00
30125-00023-00
20090-01329-00
34030-00009-00
33301-00010-00
20196-00122-00
31002-00013-00
20217-00038-00
20196-00271-00
20196-00272-00
33126-00008-00
33580-00035-00
20135-00283-02
33015-00012-00
30101-00355-00
20014-00117-03
34030-00079-00
30101-00341-00
33141-00027-00
34031-00027-00
30136-00086-00
34006-00020-00
20134-00024-00
34023-00197-00
34023-00198-00
34038-00057-00
Description
Hexagon flange nut M10
Vibration damping support
Vibration damping support A
Damping support B
Hexagon flange nut M8
Rack components
Single head bolt shock absorber
Plum-shaped spring cushion
Harness parts
Battery
Battery pressure plate
Harness parts
Harness parts
Plug
Handle fixing pin
Handle tube assembly
Handle rubber sleeve
Hexagon flange bolt M8*16
Bracket parts
Damping rubber pad
Hex flange bolt M6*16
Hubcaps
Axle pin
Flat Washers
Cotter pin
Wheel assembly
Snorkel
Snorkel
Carbon canister
