IQaudIO PI-DAC+ - Connecting Speakers to Pi-AMP+

For accurate performance, your loudspeakers must be connected in phase. For both left and right
loudspeakers.
P3 is for connecting the RIGHT speaker P2 is for connecting the LEFT speaker
!
Attach the speaker -ve terminal (often black) to the - on the amplifier output
Attach the speaker +ve terminal (often red) to + on the amplifier output
