iRobot Scooba - Bottom View Components

Scooba 400 Series Owner’s Manual 9
EN
Charging Contacts (For use
with Scooba
®
DryDock
™
Charging and Drying Stand)
Battery Cover
Front Caster
Wheel
Dry Debris
(Curved) Brush
Vacuum Squeegee
Water Distribution (Straight) Brush
Cleaning Head Assembly
Scooba has two main parts: the robot base and the tank.
Tank
1. Clean Compartment Cap (Blue)
2. Dirty Compartment Cap (Gray)
3. Tank Filter
Robot Base
1. Cleaning Head
Eject Button
1
3
2
Bottom View
Roller Brush Cover Release Latch
Roller Brush
Roller Brush Cover
