Ironman4x4 BBC080 - Wiring Diagrams; Fog Lights

Page 12 of 14
BBC/BBCD080Installation Guide
©Copyright 2024 Ironman 4x4 Pty Ltd. No part of this publication may be reproduced or replicated without the prior written consent of Ironman 4x4 Pty Ltd
Document Number: BBC_BBCD080/300424
Wiring Diagrams
Blue
Relay
Connector
Ground
Fuse
Red
3085
86
87
87a
Red Lamp
Black
Lamp
Positive power supply
at connector to factory fog light
WITHOUT FACTORY FOG LIGHTS
FOG LIGHTS
DRL/PARKING/INDICATOR LIGHTS
If vehicle is not fitted with DRL, leave red wire disconnected
Daytime Running Light
Park Light
Indicator Light
Battery
Blue
White
White
Brown
Red
Yellow
Ground
Parklight
Relay
Connector
Ground
Fuse
Red
3085
86
87
87a
Red Lamp
Black
LampBattery
Ground
Ground
Switch
SPST
