Page 13 of 14
BBC/BBCD080Installation Guide
©Copyright 2024 Ironman 4x4 Pty Ltd. No part of this publication may be reproduced or replicated without the prior written consent of Ironman 4x4 Pty Ltd
Document Number: BBC_BBCD080/300424
Wiring Diagrams
LIGHTBAR
CONNECTOR
40A
8586
30
87
8586
30
87
85 86 30 8785 86 30 87
2 1
40A
VEHICLE BATTERY
FIREWALL
CONNECTOR
IPL
CONNECTOR
FIREWALL
CONNECTOR
IN CABIN ROCKER
SWITCH LIGHTBAR
IN CABIN ROCKER
SWITCH SPOTLIGHT
IN CABIN ROCKER
SWITCH LIGHTBAR
LIGHTBAR
OEM SWITCH
SPOTLIGHT
OEM SWITCH
LIGHTBAR OEM
SWITCH ADAPTOR
SPOTLIGHT OEM
SWITCH ADAPTOR
LIGHTBAR
RELAY
SPOTLIGHT
RELAY
SPOTLIGHT
CONNECTOR
SPOTLIGHT
CONNECTOR
IN CABIN ROCKER
SWITCH SPOTLIGHT
LIGHTBAR OUTPUT (RED)
BATTERY (RED)
LIGHTBAR TRIGGER (WHITE)
NEGATIVE HIGHBEAM TRIGGER (BLACK)
GROUND (BLACK)
BATTERY (RED)
LIGHTBAR (RED)
GND (BLACK)
PARKER (BROWN)
SPOTLIGHT OUTPUT (RED)
BATTERY (RED)
SPOTLIGHT TRIGGER (ORANGE)
NEGATIVE HIGHBEAM TRIGGER (BLACK)
PARKER (BROWN)
SPOTLIGHT (RED)
GROUND (BLACK)
PARKER (BROWN)
SPOTLIGHT (RED)
GROUND (BLACK)
NEGATIVE HIGHBEAM TRIGGER (BLACK)
POSITIVE HIGHBEAM TRIGGER (GREEN)
PARKER (BROWN)
LIGHTBAR TRIGGER (WHITE)
SPOTLIGHT TRIGGER (ORANGE)
PARKER (BROWN)
POSITIVE HIGHBEAM TRIGGER (GREEN)
NEGATIVE HIGHBEAM TRIGGER (BLACK)
NEGATIVE HIGHBEAM TRIGGER (BLACK)
POSITIVE HIGHBEAM TRIGGER (GREEN)
PARKER (BROWN)
LIGHTBAR TRIGGER (WHITE)
SPOTLIGHT TRIGGER (ORANGE)
POSITIVE HIGHBEAM (RED)
LIGHTBAR TRIGGER (WHITE)
PARKER (BROWN)
NEGATIVE HIGHBEAM TRIGGER (BLACK)
LIGHTBAR TRIGGER (WHITE)
POSITIVE HIGHBEAM TRIGGER (RED)
LIGHTBAR TRIGGER (WHITE)
POSITIVE HIGHBEAM TRIGGER (RED)
SPOTLIGHT TRIGGER (ORANGE)
POSITIVE HIGHBEAM TRIGGER (RED)
SPOTLIGHT TRIGGER (ORANGE)
NEGATIVE HIGHBEAM
TRIGGER (BLACK)
NEGATIVE HIGHBEAM
TRIGGER (BLACK)
POSITIVE HIGHBEAM TRIGGER (RED)
SPOTLIGHT TRIGGER (ORANGE)
1 2 3
1 2
3
1 2
3
1 2
2 1
3
1 2 3 54
3 2 1
3 2 1
1 2 3 54
1 2 3 54
1 2 3 54
5 4 3 12
5 4 3 12
5
4
3
6 1
2
1 2 3 54
5 4 3 12
5 4 3 12
5 4 3 12
1
2
3
6 5
4
SPOTLIGHT
CONNECTOR
CUBE LIGHT
ADAPTOR
GROUND (BLACK)
SPOTLIGHT (RED)
CUBE LIGHT (RED)
GROUND (BLACK)
3 2 1
2 1
3
1
2
1 2
SPOTLIGHT
CONNECTOR
CUBE LIGHT
ADAPTOR
GROUND (BLACK)
SPOTLIGHT (RED)
CUBE LIGHT (RED)
GROUND (BLACK)
3 2 1
1
2
1 2
IDLWL001
WIRING LOOM TO SUIT
7” SCOPE DRIVING LIGHTS
OPTIONAL
Plug and Play Kit
for Factory Style
Aftermarket Switch
OPTIONAL
Rocker Switches
NOTE:
IF HARNESS IS NOT BEING USED
WITH IRONMAN 4X4 IPL HARNESS,
PIN 1 (BLACK) ON IPL PLUG MUST
BE CONNECTED TO GROUND
RED WIRE
WHITE WIRE
RED WIRE
ORANGE WIRE
IDLWL007C
CUBE LIGHT ADAPTORS
2 1
3
IDLWL001 WIRING LOOM TO SUIT SCOPE 7” DRIVING LIGHTS
PLEASE REFER TO LIGHT WIRING INSTRUCTIONS FOR SCOPE 9” DRIVING LIGHTS
To Next Page
