Irritrol Dial Series User Manual

22
- CONTINUED
OPTION l: SIX-DAY
WATERING SCHEDULE
To give you greater flexibility, the watering calendar may be changed
from its factory setting of 14 days to 6 days. This change affects both
programs A and B. This feature provides for watering every day, every
other day, every third day, or every sixth day.
1.
Set the dial to the Options position.
2.
Use the Advance A or Advance V buttons to select option 1.
3.
Press the On A button.
To return to a 14-day schedule:
1.
Set the dial to the Options position.
2.
Use the Advance A or Advance V buttons to select option 1.
3.
Press the Off V button.
OPTION 2: PROGRAMMING
WATER TIME IN SECONDS
This feature changes all stations’ watering times in program B to
seconds. The watering time duration is from 0.1 minute to 9.9 minutes
in 0.1 -minute (6-second) increments.
1.
Set the dial to the Options position.
2.
Use the Advance A or Advance V buttons to select option 2.
3.
Press the On A button.
To return to minutes mode (1 min. to 99 mm):
I.
Set the dial to the Options position.
2.
Use the Advance A or Advance V buttons to select option 2.
3.
Press the Off V button.
Using Advanced Features
- CONTINUED
OPTION 3: PROGRAMMING
WATER TIME IN HOURS
This feature changes all stations’ watering times in program B to hours.
The watering time duration is from 0.1 hour to 9.9 hours in 0.1 -hour
(6-minute) increments.
1. Set the dial to the Options position.
2. Use the Advance A or Advance V buttons to select option 3.
3. Press the On A button.
To return to minutes mode (1 min. to 99 min.):
1. Set the dial to the Options position.
2. Use the Advance A or Advance V buttons to select option 3.
3. Press the Off ‘I button.
NOTE:
The controller will not allow you to activate both
seconds (option 2) and hours (option 3) at the same
time.If one of these options is “ON” and another is
selected as “ON,” the first option will be turned off
automatically. For example, if option 2 has been selected
as “ON” and option 3 is then selected as “ON,” option 2
will be turned off.

Irritrol Dial Series Specifications

General

Start Times	3 start times per program
Enclosure	Indoor/Outdoor
Rain Sensor Compatible	Yes
Master Valve/Pump Start	Yes
Cycle and Soak	Yes
Manual Operation	Yes
Enclosure Rating	NEMA 3R
Zones	4, 6, 12
Programs	3 independent programs
Watering Schedule	7-day calendar
Power Source	AC power
Backup Battery	9V battery
Mounting	Wall mount
Programming	Dial
Water Budget	10% to 200%
Watering Duration	1 minute to 6 hours per zone
Backup Memory	Non-volatile memory
