© IS Technologies Co., Ltd. PAGE 11 / 41
2. Specification
ULM-1000C
Measurement Ultrasonic non-contacting
Measuring Range 0.3 to 6.0m (0.98 to 19.6 )
Accuracy
%0.2 of F.S
Bean Angle 8
˚at -3dB
Resolution 1mm or 0.03% of F.S
Damping Rate 0.1m/min - 100m/min adjustable
Output Analog Analog
~4 20mA, into max 60 Ω0
Display 5 Digit LCD
Material Polypropylene
IP Rating IP67
Process Connection 2” PF
Temperature -20℃
~ 70℃(-4℉~ 158℉) for Sensor
-20℃
~ 60℃(-4℉~ 140℉) for LCD
Temperature Compensation by a built-in temperature sensor
Dimension 117
×(W) 120(H)x209(D) mm
Weight ca. 1kg
Power Supply DC 20
~ 30V
Power Consumption less than 0.022A
* The Specication is subject to change without prior notice.
