Specifications
Type: UC1
Power input port: XT60
Input voltage: 2~6S LiPo (7.4~26V)
Max output current: 2A
Max output power: 18W
Charging protocol support:
QC2.0/3.0, FCP, BC 1.2
Operating temperature: 0 ~40 ℃
Size: (L × W × H) 48.5×22×14.5mm
Weight: 23 g
Indicator light status
Indicator
light
Instructions
Output
Solid green
light
Red light
quick flash
Red light
slow flash
Purple light
slow flash
Cyan light
slow flash
Charging
Internal circuit
abnormal,
charging stop
Low voltage
alarm,
the flash times
is the number
of battery cells
The input
voltage is
higher than
the battery
cells setting
Setting
state
