ICP 3020 / ICP 4030 iMC-P Operating instruction
page 15
6 Assembly and operation
On delivery:
 are all control elements to the security circuit of the machine control
 is the main spindle drive (without speed control 100-230VAC 500 – 750 W or with
speed control 750W )
 are depending on customer requests additional actors or sensors
already connected.
6.1 Safety notes
The work on the electrical installation must be performed by authorized and
trained personnel. Any changes to the electrical installation will void the
warranty and CE conformity. In additions to the machine (e.g. spindle, drives,
actuators, sensors, etc.) the operator is responsible for ensuring that all safety
rules are followed in accordance with EN 60204-1.
Please not the technical data of the machine as well as the connections.
