Isel ICP 4030 User Manual

ICP 3020 / ICP 4030 iMC-P Operating instruction
page 39
11 Technical data
11.1 Dimensions and weight
data
ICP 3020
ICP 4030
dimensions W x D x H
[mm]
610 x 650 x 715
780 x 835 x 810
movement area
X axis
[mm]
300
400
Y axis
[mm]
200
300
Z axis
[mm]
90
140
axis speeds (X/Y/Z on 10mm spindle gradient)
>100/100/80
>100/100/80
pass through height
[mm]
115
150
clamping table (WxD)
[mm]
250 x 250
600 x 375
T-slot raster
[mm]
25
25
approx. weight
[kg]
85
150
sound pressure level
[db(A)]
<75
<75
11.2 Drive
Driving the axles is realized by 2 phase stepper motors:
data
ICP 3020
ICP 4030
spindle Ø
[mm]
16
16
spindle gradient
X axis
[mm]
10
10
(standard version)
Y axis
[mm]
10
10
Z axis
[mm]
10
10
motor in standard version (X/Y/Z)
[W]
120/120/120
120/120/120
11.3 Electrical data
Net input
net power supply voltage:
100 - 230VAC 50/60 Hz, 16A
fuse:
net input 2 x 6,3A / 250V, time-lag
ground:
complies with protection class 1
Stepper motor power amplifiers
max. peak current per amplifier:
4,2 A
max. rated current per amplifier:
3,0 A
supply voltage of the power amplifiers:
48 VDC
automatic current reduction:
on 50%
Electrical connections
digital inputs:
8 x inputs
digital outputs:
8 x transistor outputs 24VDC/300 mA
1 x relay output 230V/6A
analog output:
1 x analog output 0…10V to drive a main working
spindle via frequency inverter
motor brake in Z axis:
Yes
Safety
safety data:
EN ISO 13849-1:2006 category 2, PL c
Working spindle
main spindle:
500W, 11000-25000 U/min, fix wired
