ICP 3020 / ICP 4030 iMC-P Operating instruction
page 5
1 Introduction
This manual contains the operation instruction for machinery of type ICP with iMC-P
stepper motor control.
The machine is delivered fully assembled on a pallet. In the scope of delivery of the ICP
3020 / 4030 is included:
 machine case inclusive :
o three drive axles with ball screw spindle 16 x 10mm, 5mm, 4mm or 2,5mm,
2 phase stepper motors with two limit switches
o protection hood with solenoid interlock
 stepper motor control behind the backplane of the machine inclusive:
o net input filter with main switch and fuses
o 2 phase stepper motor power amplifiers up to 4 axes with 4A rated current
o base board with processor (core module)
o security circuit module (SC module)
o 48V and 24V power supply unit
o Function keys and emergency stop switch on the machine front side
o net cable
o communication cable
 drilling / milling machine with 3 mm collet
 wrench for collet, wrench opening 22
 clamping set (lever, stop rails, 5 mm hexagon wrench )
 triangular wrench to unlock the protection hood
 4-fold power strip with lighted main switch
 Remote as control software (optional: ProNC)
 CAD/CAM software isyCAD/CAM 2.5 Plus (optional)
 operating instruction
Please note this manual that you
• install and do commissioning of CNC machine correctly
• can work safety, fast and effectively
• keep away danger from persons and the equipment
• can fully profit from the capabilities of CNC machine.
