ICP 3020 / ICP 4030 iMC-P Operating instruction
page 25
Analog - Out, Sub-D9-pin connector
Use this connector to drive an external frequency inverter with the corresponding working
spindle via a 0 – 10 V analog output.
Cover - Sub-D9-pin connector
This connector is used to integrate a solenoid interlock to the security circuit of the
controller.
On isel machines the solenoid interlock is realized by a switch of
type: SCHMERSAL EX-AZM 170-02ZK-24V
Only this type interlocks or interlocks with the same functionality
have to be used.
pin
description
1
+24VDC
2
n.u.
3
n.u.
4
make contact 1(potential free contact)
5
analog 0 ...10V
6
GND
7
n.u.
8
make contact 1(potential free contact)
9
GND
pin
description
1
+ coil break contact
2
switch 1.1 (bridge to pin 3 if no safety door is used)
3
switch 1.2 (bridge to pin 2 if no safety door is used
4
switch 2.1 (bridge to pin 5 if no safety door is used
5
switch 2 .2 (bridge to pin 4 if no safety door is used
6
- coil break contact
7 - 9
n.u.
If no cover or safety door is used the pins 2, 3 and 4, 5 must be
bridged. Therefore use the enclosed Sub-D 9-pin plug.
If the contacts of the interlock is interrupted (e.g. forcible opening of
the hood or remove the jumper, Sub-D) will immediately trigger an
emergency stop and turned off the spindle.
