Manual No. 085-3435-07 3/45 IGB/IGX Series (Overseas Specifications) Service Manual
Chapter 1. Product Overview
1.1 Machine Outline
• The base of software used is the same as that of the IGB and IGX Series. Therefore, the Setup and
Test mode items are same as those of the IGB and IGX Series. The machine functions are available
within these standard specifications.
• A check function of the upper and lower weight limits are standardly provided with the IGB and IGX
Series.
• The main board is different from that of the IGB and IGX Series. However, basic operations are same
for these models.
• For the IGB Series, an LCD is adopted, and either two dry batteries or an AC adapter can be used as a
power source.
• For the IGX Series, a VFD is adopted, and a wide selection of power sources ranging from 100 VAC to
240 VAC is available.
1.2 Standard Specifications
Item Contents
IGB Series IGX Series
Model Name
IGB-60 IGB-150 IGX-60 IGX-150
OIML R76 Class III
Weighing Capacity 60kg 150kg 60kg 150kg
Graduation 0.02kg 0.05kg 0.02kg 0.05kg
Accuracy 1/3000
Non-OIML (ASIA)
Weighing Capacity 60kg 150kg 60kg 150kg
Graduation 0.01kg 0.02kg 0.01kg 0.02kg
Accuracy 1/6000 1/7500 1/6000 1/7500
lb/kg Switching Specification (USA)
Weighing Capacity 150lb/60kg 300lb/150kg 150lb/60kg 300lb/150kg
Graduation 0.05lb/0.02kg 0.1lb/0.05kg 0.05lb/0.02kg 0.1lb/0.05kg
Accuracy 1/3000
Weighing Platter 550mm (L) x 400mm (W)
Exterior Material
Display: ABS resins
Display pole: Aluminum die-cast
Weighing platter: Stainless (SUS304)
Display Angle Adjust Angle adjustable from the horizon (0°) to the front, Knob locking method
Weight 16.0kg (excluding batteries) 16.8kg
Environmental
Condition
Temperature from -5°C to +40°C, Relative humidity 80%RH (max.) without condensation
