Iskra MC330 User Manual

CONNECTION

Measuringcentres–M
C
320,MC330,MC350&MC350H ‐ User’sManual 13

CONNECTION
Introduction
Thischapterdealswiththeinstructionsformeasuringcentreconnection.Boththeuseandconnectionofthe
deviceincludeshandlingwithdangerouscurrentsandvoltages.Connectionshallthereforebeperformedbya
qualifiedperson.Iskra,d.d.doesnottakeanyresponsibilityregardingtheuseandconnection.Ifanydoubtoccurs
regardingconnectionanduseinthesystemwhichdeviceisintended for, please contact a person who is
responsibleforsuchinstallations.

Beforeuse:Checkvoltagesandphaserotation,supplyvoltageandnominalfrequency.

Check protective fuse rating (the recommended maximum rating of the external protective fuse for this
equipmentis6A‐RedSpottypeorequivalent).

WARNING!

Wrongorincompleteconnectionofvoltageorotherterminalscancausenon‐operationor
damagetothedevice.

PLEASENOTE

Afterconnection,settings have to beperformedviaa keyboardonthefrontsideofthe
instrumentthatreflectconnectionofdevicetovoltagenetwork(connectionmode,current
andvoltagetransformersratio,…).
