CONNECTION

1
6
 Measuringcentres– M
C
320,MC330,MC350&MC350H‐User’sManual


Connection4u(3W4u)
Threephase,fourwire
connectionwithunbalanced
load

PLEASENOTE

Examplesofconnectionsareshownwithoutinput/outputmodulesandcommunication.
Connectiondoesnotdependonanumberofbuilt‐inmodulesandcommunication,andis
shownonthedevicelabel.
Connectionofinput/outputmodules
WARNING!

Check the module features that are specified on the label, before connecting module
contacts.Wrongconnectioncancausedamageordestructionofmoduleand/ordevice.

PLEASENOTE

Frequencyofthetariffinputvoltagesignalshouldnotessentiallydeviatefromthefrequency
ofthemeasuringinputsignal.Atnosignalonthemeasuringinputsthetarifftriggeringis
notreliable.

3 Connectmodulecontactsasspecifiedonthelabel.Examplesoflabelsaregivenbelowanddescribe
modules built in the device. Information on electrical properties of modules is given in chapter
Modulesonpage49.

Tariff input module with two tariff inputs for
changeoverbetweenuptofourtariffs.

Tariff input module with two tariff inputs for
changeoverbetweenuptofourtariffs.

S0 (pulse) output module with two pulse
outputsforenergycounters.

Relay output module with two outputs.
(MC330,MC350,MC350Honly)

