SETTINGS

Measuringcentres
–
MC320,MC330,MC350&MC350H ‐ User’sManua
l
2
9

Display
Displaysettings  
Acombinationofsettingofthecontrastandbacklightdefinesvisibilityandlegibilityofadisplay.Displaysettings
shallbedefinedincompliancewiththeconditionsinwhichitwillbemonitored.Economizingmodeswitchesoff
backlightaccordingtothesettimeofinactivity.
MainmenuSettingsLCDContrast/Backlight/Backlighttimeoff
Democyclingperiod  
ItdefinestimeinsecondsforeachdisplayedscreenofmeasurementsonLCD.
MainmenuSettingsLCDDemocyclingperiod
Settingsofcustomizedscreens(MC350,MC350HandMC330only)  
Foreasier and faster survey ofmeasurements that are importantfortheuser,threesettingsofcustomized
screensareavailable.Eachcustomizedscreendisplaysthreemeasurements.Whensettingcustomizedscreens
thedesignationsaredisplayedinshorterform,withupto4characters.Forsurveyofalldesignationsseechapter
SurveyofsupportedmeasurementsregardingConnectiononpage13.

Example:
Desiredresult:
Customizedscreen1 Customizedscreen2 Customizedscreen3
Phasevoltage1
Totalcurrent Powerangle(U
1
‐I
1
)
Phasecurrent1
Neutralcurrent Frequency
Phasepower1 Averagecurrent THDofcurrentI
1

Setting:
MainmenuSettingsLCDCustomscreen1/2/3

Customizedscreen1  Customizedscreen2 Customizedscreen3



MainmenuMeasurementsPresentvaluesCustomOK

 


