APPENDIXA:MODBUSPROTOCOL

5
6
 Measuringcentres
–
MC320,MC330,MC350&MC350H‐User’sManua
l

Parameter
MODBUS
100%value
Register Type
PowerAngleU
1
−I
1
30836 T17 100°
PowerAngleU
2
−I
2
30837 T17 100°
PowerAngleU
3
−I
3
30838 T17 100°
PowerAngleatan2(Pt,Qt) 30839 T17 100°
AngleU
1
−U
2
30840 T17 100°
AngleU
2
−U
3
30841 T17 100°
AngleU
3
−U
1
30842 T17 100°
Frequency 30843 T17 Fn+10Hz
THDI
1
30845 T16 100%
THDI
2
30846 T16 100%
THDI
3
30847 T16 100%
THDU
1
30848 T16 100%
THDU
2
30849 T16 100%
THDU
3
30850 T16 100%
THDU
12
30851 T16 100%
THDU
23
30852 T16 100%
THDU
31
30853 T16 100%
MaxDemandSinceLastReset  
MDRealPowerP(positive) 30854 T16 Pt
MDRealPowerP(negative) 30855 T16 Pt
MDReactivePowerQ−L 30856 T16 Pt
MDReactivePowerQ−C 30857 T16 Pt
MDApparentPowerS 30858 T16 Pt
MDCurrentI
1
30859 T16 In
MDCurrentI
2
30860 T16 In
MDCurrentI
3
30861 T16 In
DynamicDemandValues  
MDRealPowerP(positive) 30862 T16 Pt
MDRealPowerP(negative) 30863 T16 Pt
MDReactivePowerQ−L 30864 T16 Pt
MDReactivePowerQ−C 30865 T16 Pt
MDApparentPowerS 30866 T16 Pt
MDCurrentI
1
30867 T16 In
MDCurrentI
2
30868 T16 In
MDCurrentI
3
30869 T16 In
Energy  
EnergyCounter1 30870 T17
Actual
countervalue
MOD20000is
returned
EnergyCounter2 30871 T17
EnergyCounter3 30872 T17
EnergyCounter4 30873 T17
ActiveTariff 30879 T1 
InternalTemperature 30880 T17 100°


