APPENDIXB:DNP3COMMUNICATIONPROTOCOL

Measuringcentres
–
MC320,MC330,MC350&MC350H ‐ User’sManua
l
61

36
j2(anglebetweenU2andI2) T17 Data ‐100° +100° 
37
j3(anglebetweenU3andI3) T17 Data ‐100° +100° 
38
PowerAngleTotal(atan2(Pt,Qt)) T17 Data ‐100° +100° 
39
j12(anglebetweenU1andU2) T17 Data ‐100° +100° 
40
j23(anglebetweenU2andU3) T17 Data ‐100° +100° 
41
j31(anglebetweenU3andU1) T17 Data ‐100° +100° 
42
Frequency T17 Data Fn‐10Hz Fn+10Hz 
43
Uunbalace T16 Data ‐100% +100% 
44
I1THD% T16 Data ‐100% +100% 
45
I2THD% T16 Data ‐100% +100% 
46
I3THD% T16 Data ‐100% +100% 
47
U1THD% T16 Data ‐100% +100% 
48
U2THD% T16 Data ‐100% +100% 
49
U3THD% T16 Data ‐100% +100% 
50
U12THD% T16 Data ‐100% +100% 
51
U23THD% T16 Data ‐100% +100% 
52
U31THD% T16 Data ‐100% +100% 

MAXDEMANDSINCELASTRESET     
53
ActivePowerTotal(Pt)‐(positive) T16 Data ‐Pt +Pt 
54
ActivePowerTotal(Pt)‐(negative) T16 Data ‐Pt +Pt 
55
ReactivePowerTotal(Qt)‐L T16 Data ‐Pt +Pt 
56
ReactivePowerTotal(Qt)‐C T16 Data ‐Pt +Pt 
57
ApparentPowerTotal(St) T16 Data ‐Pt +Pt 
58
I1 T16 Data ‐In +In 
59
I2 T16 Data ‐In +In 
60
I3 T16 Data ‐In +In 

DYNAMICDEMANDVALUES     
61
ActivePowerTotal(Pt)‐(positive) T16 Data ‐Pt +Pt 
62
ActivePowerTotal(Pt)‐(negative) T16 Data ‐Pt +Pt 
63
ReactivePowerTotal(Qt)‐L T16 Data ‐Pt +Pt 
64
ReactivePowerTotal(Qt)‐C T16 Data ‐Pt +Pt 
65
ApparentPowerTotal(St) T16 Data ‐Pt +Pt 
66
I1 T16 Data ‐In +In 
67
I2 T16 Data ‐In +In 
68
I3 T16 Data ‐In +In 

ENERGY     
69
EnergyCounter1 T17 Data  
(32‐bit value) MOD
70
EnergyCounter2 T17 Data  
(32‐bit value) MOD
71
EnergyCounter3 T17 Data  
(32‐bit value) MOD
72
EnergyCounter4 T17 Data  
(32‐bit value) MOD
73
EnergyCounter1Cost T17 Data  
(32‐bit value) MOD
74
EnergyCounter2Cost T17 Data  
(32‐bit value) MOD
75
EnergyCounter3Cost T17 Data  
(32‐bit value) MOD
76
EnergyCounter4Cost T17 Data  
(32‐bit value) MOD
77
TotalEnergyCounterCost T17 Data  
(32‐bit value) MOD
78
AktivTariff T1 Data   
79
InternalTemperature T17 Data ‐100° +100° 

