Bit Name 0 1
0 ACTIVE Inactive Active (default)
4 THIRD_POINT_ACTIVE No decimal Decimal (default)
Table 7. Configuration of temperature sensor
HUMIDITY_CONFIGURATION:allows to configure the humidity sensor with two bits:
ACTIVE, bit 0: activates or deactivates the sensor;
Modbus register: 40317;
BACnet object: AI5, property: Out Of Service;
THIRD_POINT_ACTIVE, bit 4: enables or disables decimal values in the sensor;
Modbus register: 40317;
BACnet object: AI5, property: 4202;
Bit Name 0 1
0 ACTIVE Inactive Active (default)
4 THIRD_POINT_ACTIVE No decimal Decimal (default)
Table 8. Configuration of humidity sensor
CO2_CONFIGURATION:allows to activate or deactivate the CO2 sensor:
ACTIVE, bit 0: activates or deactivates the sensor;
Modbus register: 40318;
BACnet object: AI6, property: Out Of Service;
Bit Name 0 1
0 ACTIVE Inactive Active (default)
Table 9. Activating CO2 sensor
SETPOINT_CONFIGURATION:allows to configure the temperature setpoint with five bits:
VISIBLE, bit 0: enables or disables the temperature setpoint to be visible on the panel's
display;
Modbus register: 41513;
BACnet object: AV56, property: Out Of Service;
EDITABLE, bit 1: enables or disables editing of the temperature setpoint locally from
the panel;
Modbus register: 41513;
BACnet object: AV56, property: 4200;
OPERATING_MODE, bit 2: allows to set the operating mode of the temperature
setpoint configuration;
Modbus register: 41513;
BACnet object: BO55, property: Out Of Service;
SETPOINT_DISPLAY, bit 3: allows to configure the temperature setpoint display;
Modbus register: 41513;
BACnet object: BO56, property: Out Of Service;
