6 Fan Control
This feature allows a user to control ventilation devices through the following parameters
or in the iSMA Configurator:
FAN_MODE:allows to select a fan mode. There are up to 5 different fan modes, which
can be selected locally from the panel.
Register Value Fan Mode
0 Off (default)
1 Manual, speed 1
2 Manual, speed 2
3 Manual, speed 3
4 Auto
Table 14. Fan modes
Modbus register: 41602;
BACnet object: MSV1, property: Present Value;
FAN_CURRENT_SPEED: allows to set the fan operating speed and mode according to the
table below:
Register Value Fan Mode Description
0 Off (default) Fan is off
1 Manual speed 1 Fan works in speed 1, manual mode
2 Manual speed 2 Fan works in speed 2, manual mode
3 Manual speed 3 Fan works in speed 3, manual mode
4 Auto speed 1 Fan works in speed 1, auto mode
5 Auto speed 2 Fan works in speed 2, auto mode
6 Auto speed 3 Fan works in speed 3, auto mode
Table 15. The FAN_CURRENT_SPEED register values
Modbus register: 41601;
BACnet object: MSV0, property: Present Value.
This value can be updated in two ways depending on the FAN_CONFIG_LOCAL_MODE
parameter:
FAN_CONFIGURATION, bit 6: FAN_CONFIG_LOCAL_MODE:allows to set the fan to work
either in the local mode or BMS mode:
Local Mode: the panel's fan setting works in a local mode (the value of the
FAN_CURRENT_SPEED register is determined by the value of the FAN_MODE register and
