Modbus
Address
Decimal
Address
Hex Register Name Access Default
Value
Value
Range
Description
40001 0 0x00 VERSION_TYPE Read/
write
Shows a firmware
version and type of the
panel and enables 1 of 4
available actions (reset
device, reload settings,
reset settings, enter
bootloader)
30002 1 0x01 ADDRESS_ROTARY_
SWITCH
Read-
only
0-9 Address set on a rotary
switch
30003 2 0x02 PROTOCOL_DIPSWI
TCH
Read-
only
0-1 Protocol set on a DIP
switch
30004 3 0x03 RECEIVED_FRAMES_
COUNTER
Read-
only
0 The number of received
Modbus frames reset at
the start of the panel
and at the change of
transmission
parameters
30006 5 0x05 ERROR_FRAMES_CO
UNTER
Read-
only
0 The number of received
error Modbus frames
reset at the start of the
panel and at the change
of transmission
parameters
30008 7 0x07 TRANSMITTED_FRA
ME_COUNTER
Read-
only
0 The number of
transmitted Modbus
frames reset at the start
of the panel and at the
change of transmission
parameters
30012 11 0x0B LIVE_TIME Read-
only
Uptime of the panel in
seconds
40015 14 0x0E BACNET_DEVICE_ID Read/
write
0xFFFFFF
FF
Device's BACnet ID
40017 16 0x10 BAUD_RATE Read/
write
11520 Sets the baud rate
40018 17 0x11 STOP_BITS Read/
write
1 1-2 Sets the number of stop
bits
40019 18 0x12 DATA_BITS Read/
write
8 7-8 Sets the number of data
bits (Modbus ASCII
requires 7 bits)
