IST 18.BF200D - Parts Shipped with Engine

18-5
18. BF200D • BF225D • BF
250D iST
®
PARTS SHIPPED WITH ENGINE
Ref.
No.
Description
BF200D BF225D BF250D
Part No. Remarks
LDA • XDA
XCDA
LDA • XDA • UDA
XCDA • UCDA
LDA • LDS
XDA • XDS
UDA • UDS
XCDA • XCDS
UCDA • UCDS
1Fuel tube assembly 1111 1 1 17700-ZX2-C02
2 12.5 mm band tube clip 1111 1 1 17704-ZV4-010
3Under-case grommet 1111 1 1 40105-ZVL-000
4Separate cover 1111 1 1 40151-ZVL-000
5 Gear case cover — 1 — 1 — 1
41102-ZX2-E00ZA
or
41102-ZX2-E00ZD
Aqua Marine
or
Grand Prix White
6
Tool kit
Grip, screwdriver 1 — 1 — 1 — 99003-50000
Screwdriver 1 (No.2 Phillips) 1 — 1 — 1 — 99003-10000
Hex wrench 1 — 1 — 1 — 89221-371-000
19 mm eye wrench 1 — 1 — 1 — 99006-19000
Wrench, plug 1 — 1 — 1 — 89216-SF4-000
Box wrench 1 — 1 — 1 — 89217-355-000 (2)
Tool bag 1 — 1 — 1 — 89101-ME5-670
7 6 x 25 mm flange bolt 2222 2 2 90109-ZVL-000
Use with
Ref. No. 4
8 12 x 130 mm hex bolt 6666 6 6 90129-ZX2-000
Outboard motor
installation
9 12 x 22 mm plain washer 12 12 12 12 12 12 90559-ZV5-000
1012 x 33 mm plain washer 6666 6 6 90552-ZV5-000
11 12 mm hex nut 12 12 12 12 12 12 94001-12490-0S
1218 mm propeller castle nut 1111 1 1 90301-ZW1-B00
Propeller
installation
13 Propeller thrust washer 1111 1 1 90506-ZX2-C00
14 Propeller washer 1111 1 1 90512-ZX2-C00
154 mm split pin 1111 1 1 90758-ZW1-B00
16 Owner’s Manual (English) 1111 1 1 (1) Give to customer
17Emission hang tag (CARB 3 stars)1111 1 1 TM052
18Oil caution tag 1111 1 1 N/A
19Harness band clip 1111 1 1 91541-S0A-003
20Prop 65 hang tag 1111 1 1 N/A
(1) To order Owner’s Manuals, call Service Publications at 800-222-7693 (option 7).
