18-8
18. BF200D • BF225D • BF250D iST
®
TYPICAL RIGGING TABLES
SINGLE ENGINE, FLUSH-MOUNT CONTROL
See page 18-29 for rigging diagram.
• A water separator is recommended on all permanent fuel tank applications.
• Fuel-injected models must have PGM-FI light indicators, either panel or switch units.
• See the Honda Marine Rigging Components and Accessory Catalog (TM080) for all
available accessories, including propellers, control boxes, harness extensions, key
switch panels, gauges, and gauge harnesses.
QTY
REQ.
PART NUMBER PART DESCRIPTION
1 06240-ZVL-000 Box Kit, R/C (Flush Mt)
1 06326-ZVL-000 Panel Assy, Function
( 1 ) 06323-ZVL-000 Panel Kit, Key Sw (Single / Horizontal)
( 1 ) 06323-ZVL-800 Panel Kit, Key Sw (Single / Vertical)
2 06653-ZZ3-730HE Cable Kit, Interface (10 ft)
1 06330-ZZ3-000AH NMEA Backbone Starter Kit
( 1 ) 32590-ZVL-000
Cable Assy, Eng Drop (Single 6 ft) *
( 1 ) 32590-ZVL-810 Cable Assy, Eng Drop (Single 16 ft)
( 1 ) 32590-ZVL-820 Cable Assy, Eng Drop (Single 20 ft)
( 1 ) 32590-ZVL-830 Cable Assy, Eng Drop (Single 25 ft)
( 1 ) 32590-ZVL-840 Cable Assy, Eng Drop (Single 30 ft)
( 1 ) 32580-ZVL-600 Cable Assy, DBW Trunk (18 ft)
( 1 ) 32580-ZVL-700 Cable Assy, DBW Trunk (24 ft)
( 1 ) 32580-ZVL-800 Cable Assy, DBW Trunk (30 ft)
( 1 ) 06653-ZZ3-730HE Cable Kit, Interface (10 ft)
( 1 ) 06653-ZZ3-760HE Cable Kit, Interface (19.5 ft)
1 06177-ZX2-000HE 10 Micron "Spin-On" Fuel/Water Separator
* Requir
es Trunk Cable
Choose switch
Choose length
Choose length
Choose length
