IST 18.BF200D - Page 9

18-9
18. BF200D • BF225D • BF
250D iST
®
SINGLE ENGINE, FLUSH-MOUNT CONTROL, SMART KEY
See pages 18-29 and 18-47 for rigging diagrams.
QTY
REQ.
PART NUMBER PART DESCRIPTION
1 06240-ZVL-000 Box Kit, R/C (Flush Mt)
1 06326-ZVL-000 Panel Assy, Function
( 1 ) 06311-ZVL-010
Unit Kit, Smart Key (Horizontal)
( 1 ) 06311-ZVL-801
Unit Kit, Smart Key (Vertical)
2 06653-ZZ3-730HE Cable Kit, Interface (10 ft)
1 06330-ZZ3-000AH NMEA Backbone Starter Kit
( 1 ) 32590-ZVL-000
Cable Assy, Eng Drop (Single 6 ft) *
( 1 ) 32590-ZVL-810 Cable Assy, Eng Drop (Single 16 ft)
( 1 ) 32590-ZVL-820 Cable Assy, Eng Drop (Single 20 ft)
( 1 ) 32590-ZVL-830 Cable Assy, Eng Drop (Single 25 ft)
( 1 ) 32590-ZVL-840 Cable Assy, Eng Drop (Single 30 ft)
( 1 ) 32580-ZVL-600 Cable Assy, DBW Trunk (18 ft)
( 1 ) 32580-ZVL-700 Cable Assy, DBW Trunk (24 ft)
( 1 ) 32580-ZVL-800 Cable Assy, DBW Trunk (30 ft)
( 1 ) 06653-ZZ3-730HE Cable Kit, Interface (10 ft)
( 1 ) 06653-ZZ3-760HE Cable Kit, Interface (19.5 ft)
1 06177-ZX2-000HE 10 Micron "Spin-On" Fuel/Water Separator
* Requir
es Trunk Cable
V6D iST SK FM 1Eng1StaNMEAw-BB
Choose length
required
Choose switch
orientation
Choose length
required
Choose length
required
