iStorage datashur User Manual

#9
www.istorage-uk.com
iStorage datAshur
®
Manual – v 3.1
Note: A double blink indicates the drive is unlocked in Admin mode.
A single blink indicates the drive is unlocked in User mode.
If the datAshur has been reset or hacking detection has been triggered (i.e. no User or Admin PIN exist), the instructions
below can be followed. If a User PIN already exists, the datAshur must be unlocked first with the user PIN by following
instructions under section 5, before an Admin PIN can be created by following instructions below.
User PIN Admin PIN Possible Actions
NOT SET NOT SET
Can set either User or Admin PIN
Cannot access drive until User or Admin PIN
SET NOT SET
Can change User PIN when unlocked as User
Can set Admin PIN when unlocked with User PIN
Can access data when unlocked as User
NOT SET SET
Can set User PIN when drive is locked
Can unlock drive with Admin PIN
Can change Admin PIN when unlocked as Administrator
Can perform Administrator commands
SET SET
Can unlock drive with either User or Admin PIN
Can change User PIN when unlocked as User
Can change Admin PIN when unlocked as Administrator
The following table depicts the possible actions when the drive is in different states:
The drive has to be unlocked in User mode in order to proceed with configuring an Admin PIN.
It is set by following the instructions below:
INSTRUCTIONS LED ACTIVITY
Double press the KEY Button
and
hold on the 2
nd
press for 3 seconds
will double blink once and then turn solid
Enter the New Admin PIN
and press KEY Button
will double blink if correct PIN entry or
will blink alternately if PIN entry incorrect
Re - Enter the New Admin PIN
and press KEY Button
will illuminate together for approximately
2 seconds and then:
will double blink indicating correct PIN entry
Note that at this point the
following occurs:
will double blink if 1
st
and 2
nd
entries match
will blink alternately if PIN entry incorrect
Insert your datAshur into USB port
will illuminate in a constant state
Admin PIN requirements:
• Must be between 7-15 digits in length
• Must not contain only repetitive numbers, e.g. (3-3-3-3-3-3-3)
• Must not contain only consecutive numbers, e.g. (1-2-3-4-5-6-7), (7-8-9-0-1-2-3-4), (7-6-5-4-3-2-1)
• datAshur must NOT be connected to a host

iStorage datashur Specifications

General

Interface	USB 3.0 (3.1 Gen 1) Type-A
Read speed	195 MB/s
Write speed	162 MB/s
SSD capacity	240 GB
Certification	FIPS 140-2 Level 3, FIPS Pub 197 Validation, IP58
SSD form factor	-
Data transfer rate	5 Gbit/s
Password protection	Yes
Protection features	Dust resistant, Water resistant
Security algorithms	256-bit AES, FIPS 140-2, FIPS 197
Internal	No
Product color	Black
Housing material	Aluminum
Sustainability certificates	RoHS
Form factor	Sleeve
International Protection (IP) code	IP58
USB version	3.2 Gen 1 (3.1 Gen 1)
Device interface	USB Type-A
Other operating systems supported	ChromeOS
Mobile operating systems supported	Android
Keypad number of keys	12
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	93 mm
Width	24.5 mm
Height	12.6 mm
Weight	46 g
Dimensions (without sleeve) (WxDxH)	24.5 x 12.6 x 93 mm
