Note: Once unlocked, the GREEN LED will double blink for 30 seconds, within which time the drive needs
to be connected to a USB port. If no connection has been detected within 30 seconds the drive will lock.
Figure 2: Key entry for mode selection
User
Administrator
3 seconds
3 seconds
1/4 sec
Figure 1: Mode indication
Single Blink
Double Blink
User
Administrator
On On
On On On On
Off Off Off
Off
Figure 1 shows the GREEN blinking characteristics when the drive is opened in User mode (top - single blink)
and Admin mode (bottom - double blink).
Figure 2 shows the difference between pressing KEY Button to set a User PIN vs. setting the Admin PIN.
8. How to unlock with Admin PIN
INSTRUCTIONS LED ACTIVITY
Press the KEY Button twice
in succession
(similar to double-clicking a mouse)
will double blink together (Figure 1. above)
Enter Admin PIN
Press KEY Button
will illuminate together as self-tests are run
will double blink if admin entered correct PIN
will blink if incorrect PIN was entered
Caution: Entering the Admin PIN to access a locked drive will clear the User PIN. If a user forgets
their PIN, access to their drive is regained by defining a new user PIN. For security reasons, we
highly recommend that a new User PIN be created immediately once the drive has been unlocked
using the Admin PIN.
