6B–6 ENGINE COOLING
Water Pump
Disassembly
030EY00026
Legend
(1) Center
(2) Dust cover
(3) Snap ring
(4) Bearing
(5) Bearing
(6) Spacer
(7) Bearing
(8) Washer
(9) Shaft
(10) Water pump body
(11) Dowel pin
(12) Seal unit
(13) Impeller
(14) Gasket
(15) Cover
(16) Bolt
