GENERAL INFORMATION 0A–35
Location
Name of sealant
Name of part Name of mating part
1 Rubber plug Cylinder head & cover ThreeBond No. 1207B
2 Oil cooler Cylinder block
3 Crankcase Cylinder block
4 Cylinder block Flywheel housing ThreeBond No. 1207C or No.1216C
5 Cylinder block Front cover
6 Water pump Front cover
7 Oil pump Cylinder block ThreeBond No. 1207C or TB1141E
Sealant Application
Name of Lubricant Lubrication area
Engine Oil Turbocharger bearings
Cylinder head bolts (M10 bolt)
Rocker arm rollers
Camshaft cam nose and journal
Camshaft fixing bolts and stud bolts
Valve ends
Oil seal lips
Idle gear shaft & fixing bolts
Cylinder liner bores
Connecting rod bearing sliding surfaces
Crank bearing sliding surfaces
Thrust bearings
Piston rings
Molybdenum disulfide grease Cylinder head bolts
Crankcase fixing bolts
Flywheel bolts
Connecting rod bolts
Piston skirts
Lubricant Application
