GENERAL INFORMATION 0A–13
ITEMS SERVICE STANDARD SERVICE LIMIT
Rocker Arm Shaft and Rocker Arm
Rocker Arm Shaft Run-Out mm (in) 0.30 (0.012)
Rocker Arm Shaft Outside Diameter
mm (in) 21.979 – 22.000 21.85
(0.865 – 0.866) (0.860)
Rocker Arm Inside Diameter mm (in) 22.010 – 22.035
(0.867 – 0.868)
Rocker Arm Shaft and
Rocker Arm Clearance mm (in) 0.010 – 0.056 0.20
(0.0004 – 0.0022) (0.008)
Rocker Arm Pin and Roller Clearance
mm (in) 0.068 – 0.099 0.50
(0.0027 – 0.0039) (0.02)
Valve Cap Worn mm (in) 0.10 (0.004)
Camshaft
Camshaft Journal Diameter mm (in) 39.950 – 39.975 39.85
(1.5728 – 1.5738) (1.5689)
Cam Lobe Height Intake mm (in) 7.851 (0.3091) 7.351 (0.2894)
Exhaust mm (in) 9.540 (0.3756) 9.040 (0.3559)
Camshaft Run-Out mm (in) 0.025 (0.001) 0.05 (0.002)
Camshaft Bearing Inside Diameter
mm (in) 40.00 – 40.037
(1.575 – 1.576)
Camshaft Bearing Clearance mm (in) 0.025 – 0.087 0.15
(0.001 – 0.003) (0.006)
Crankshaft
Crankshaft End Play mm (in) 0.040 – 0.205 0.54
(0.0026 – 0.008) (0.021)
Crankshaft Run-Out mm (in) 0.06 (0.002) or less 0.45 (0.016)
Crankshaft Journal Diameter
See section 6A crankshaft
journal diameter in this
manual.
Crankshaft Journal and
Bearing Clearance mm (in)
No. 4 Bearing 0.093 – 0.124 0.14
(0.00366 – 0.00488) (0.0055)
Other Bearings 0.063 – 0.094 0.14
(0.00248 – 0.00370) (0.0055)
Crankshaft Journal and
Crankpin Uneven Wear mm (in) 0.05 (0.0020)
