ENGINE MECHANICAL 6A–15
5. Remove the oil feed pipe (1) from the injection pump.
6. Remove the oil return pipe (2).
7. Loosen the coupling bolts (1).
8. Remove the booster air pipe (injection pump
governor to intake cover).
9. Loosen the injection pump fixing bolts (1).
10.Remove the injection pump.
11.Remove the injection pump bracket.
