Basic Operation

4. After the parameter settings are complete, press [Enter].

Set the Parallel Mode

• Before connecting the system bus, you must ensure that each in-

strument is in single mode (Single).

• Fiber optic cables cannot be flexed or folded. When the cable is too

long and needs to be arranged, gently wrap the cable in a circle and

gently tie it.

• Before connecting the cables, ensure that the instrument power

switch is off and the main switch of the AC power input (distribu-

tion box) is off.

• Before connecting 3 single instruments to the AC distribution box,

ensure that the distribution box capacity is sufficient. Refer to the

corresponding specifications for the AC input parameters of a sin-

gle instrument.

For 3U models, up to 16 units of the same model can be connected in parallel.

Taking three 3U single instruments (with operation panel) as an example, the

steps for parallel operation are as follows.

For a parallel connection between a master unit (with operation panel) and N

slave units (without operation panel), refer to the IT6000 Parallel Assembly

Instruction or the IT6000 Cabinet Assembly Instruction.

1. Ensure that the power switches of the three units and the main switch of the

AC power distribution box are off.

2. Refer Figure 5–1 Wiring connection diagram to connect three units.

162

ITech IT6000C Series User Manual
