ITech IT6512D User Manual

Specification
Copyright ©ITECH Electronics Co., Ltd. 104
Dimension ( mm)
554mmW×902mmH×807.5mmD( ITECH 15U Cabinet )
Weight( net)
137Kg
Parameter
IT6577D Version: V1.4
Output Rating
( 0
℃
-40
℃
)
Output Voltage
0-1000V
Output Current
0-70A
Output Power
0-21KW
Line regulation
±(%of Output+Offset)
Voltage
≤0.01%+100mV
Current
≤0.01%+35mA
Load regulation
±(%of Output+Offset)
Voltage
≤0.01%+375mV
Current
≤0.05%+70mA
Setup Resolution
Voltage 100mV
Current
10mA
Power
0.1W
Read Back Resolution
Voltage
100mV
Current 10mA
Power
0.1W
Setup Accuracy
1
( within 12 months, 25
℃
±5
℃
)
(%of Output+Offset)
Voltage ≤0.05%+375mV
Current ≤0.2%+70mA
Power 1%+210W
Read Back Accuracy
2
( within 12 months, 25
℃
±5
℃
)
(%of Output+Offset)
Voltage ≤0.05%+375mV
Current ≤0.2%+70mA
Power 1%+210W
Ripple
(20Hz -20MHz)
Voltage ≤1.5Vp-p
Current
≤0.05%+70mArms
Setup Temperature
Coefficient
(%of Output/
℃
+Offset)
Voltage ≤0.01%+375mV
Current ≤0.02%+70mA
Read Back Temperature
Coefficient
(%of Output/℃ +Offset)
Voltage ≤0.01%+375mV
Current ≤0.02%+70mA
Rise time( no load ) Voltage ≤300ms
Rise time( full load ) Voltage ≤300ms
Fall time( no load )
Voltage
≤350ms
Fall time( full load )
Voltage
≤30ms
Transient Response
Time
Voltage ≤3ms
AC Input
3
Voltage
380Vac±10%(Three-phase five
wires)
Frequency
47Hz-63Hz
Setup stability-30min
( %of Output +Offset )
Voltage
≤0.05%+375mV
Current ≤0.1%+70mA
Setup stability-8h
( %of Output +Offset )
Voltage
≤0.05%+375mV
Current
≤0.1%+70mA
Readback
stability-30min
( %of Output +Offset )
Voltage
≤0.05%+375mV
Current ≤0.1%+70mA
Readback stability-8h
( %of Output +Offset )
Voltage
≤0.05%+375mV
Current
≤0.1%+70mA
efficiency
80%
Remote Sense
Compensation Voltage
3V
Command Response
Time
20mS
Power Factor
0.99
