Function and Features
Copyright ©ITECH Electronics Co., Ltd. 18
Using [Recall] (Save) button +number keys 1-9,and then pressing [Enter] button
to recall the saved parameters from specified memory region.
3.9 System Menu
Press the composite key [Shift] + [P-set] (Menu) to enter the menu function. At
this time, VFD displays optional menus. Scroll the VFD screen with Left/Right
key or knob, and the following functions will appear in sequence. Press [Enter]
to enter function options where the screen display locates. Press [Esc] to return
to previous menu.
Menu Menu setting
SYSTEM
System menu
Reset
Restore to factory defaults
Power-On
Set power on parameters
Rst( Def)
Initialize the system
Sav0
Remain last shutdown parameters
Trigger
Set the trigger mode
Manual( Def)
Manual trigger
Bus
Bus trigger
Ext
External trigger
Memory
Work with Recall(Save) button to recall 100 sets saved
parameters
Group = 0
0: represents 0-9sets;
1: represents: 10-19sets,
by parity of reasoning
Buzzer
Set the buzzer function
On( Def)
enable the buzzer function
Off
disable the buzzer function
Communicati
on
Select the communication interface
RS232( Def
)
Select RS232 communication interface
Baud rate :
4800/9600/19200/38400/57600/115200
Data bit: 8 O Odd parity 2
Parity bit: None/ E ( Even parity)/O (Odd
parity)
Stop bit: 1/2
Addr: Address=1
USB
Select USB communication interface
GPIB
Select GPIB communication interface
Address= 0
set the communication
address( 0-31)
LAN
Select LAN communication interface
