Function and Features
Copyright ©ITECH Electronics Co., Ltd. 27
List file can select any one from 100 waves. Each List file can select 10 wave
files at most and combine them into a List file based on sequence.
Each wave file has ten steps. The List file can select the wave file and set the
count of repetitions to be executed.
List function menu is as follows.
Recall List File: Need to recall list file
number.
Repeat: count of List file repetitions
Wave Count: total count of waves
contained in this List file.
1
st
Wave Select: number of the first wave
selected
1
st
Wave Repeat: count of repetitions of the
first wave selected
Yes/No: save to the file or not
Recall Wave: Need to recall Wave file
number.
Step Count: total count of steps contained
in the Wave file
Step1 Voltage: Voltage setting of step 1
Step1 Current: Current setting of step 1
Step1 Width: Width setting of step 1
Step1 Slope: Slope setting of step 1
Save to Wave: save to the Wave file
Wave edit and List edit have no order of priority.
Editing Wave
List file can arrange and link several Wave files. The user can pre-edit
several Wave files and select edited wave file that meets requirements
during usage. In this series of power supply, at most 100 wave files can be
edited.
Take an example for 3 steps, the steps of editing Wave file are as follows:
1. Press [Shift]+[I-set]( Function) to enter List operation.
2. Press to select EditWave from the menu, and press [Enter] for
confirmation.
3. Press numeric key to input the number of Wave file under edit, where
Recall Wave= 01, and press [Enter] for confirmation.
4. Press numeric key to input total count of steps for the current Wave file,
where Step Count=03, and press [Enter] for confirmation.
5. Press the numeric key to set the voltage, current, slope and width of the
Wave step 1 in sequence.
Step1 Voltage = 1V
Step1 Current = 1A
