Function and Features
Copyright ©ITECH Electronics Co., Ltd. 22
power on. Default setting is Off item.
Load Setup Option (> Load)
The power supply has an internal dummy load that can be enabled to increase
the speed of the voltage fall time for high speed test applications. Default setting
is Off status.
Load status must be set to On when use adjustable rise time and fall time
speed function.
Setting Filter
This options sets the display filter frequency of the power supply. The filter
function of this series of power supply is averaging calculation. The average
values of different frequencies are different, as shown below: Low: 2
^
16; Mid:
2^14; High: 2^8.
3.10 Setup Menu
Related power supply parameters can be set in Configuring Menu. Details are
as follows:
Voltage/current/power slope
 OVP/OCP/OPP
 Maximum and minimum values of voltage/current/power
Press [Setup] in the front panel to enter the Source menu for setting.
Setup
Source
Configure menu
Slope
Set the slope
V-Rise: voltage rise slope
V-Fall: voltage fall slope
I-Rise: current rise slope
I-Fall: current fall slope
P-Rise: power rise slope
P-Fall power fall slope
OVP
Over voltage protection
On
Enable over voltage protection
function
V: OVP value
Delay: delay time of protection
Off
Disable over
voltage
protection
function
OCP
Over current protection
On
Enable over current protection
function
I: OCP value
Delay: delay time of protection
Off
Disable over current protection
function
OPP
Over power protection
On( Def)
Enable over power protection
function
P: OPP value
