ITech IT6512D - VFD Indicator Lamps Description

Quick Start
Copyright ©ITECH Electronics Co., Ltd. 13
keys
Name and functions
Meter/( Local)
Meter button,used to switch the display between actual value
and setting value /switch to the loacl mode.
Enter/( Trigger)
Confirm button,to confirm the setting numbers or
functions/trigger button
On/Off( Lock)
Ouput on/off button,used to control the output status of power
supply/kelock function button,used to lock the front panel
buttons
Left and right direction button,used to adjust the location of the
cursor
Up and down direction button,used to select the items of the
menu or increase( decrease)
the output voltage and current
value
OK Confirm button
Esc Return key
Dot
2.4 VFD Indicator Lamps Description
IT6500D series power supply VFD indicator lamps description as follows:
Flag
Function Description
Flag
Function Description
OFF
Power supply in off mode
Timer
none
CV
Power supply in CV mode
Sense
none
CC
Power supply in CC mode
Ext
none
*
Open the keylock function
Addr
When received command
successfully,
the flag will
display 3 seconds.
Meter
“ Meter” buttion in on mode
Rmt
Remote control mode
Shift
using composite function
Error
Error occur
Rear
Analog function begin to work
Prot
Protections for OV or OT
SRQ
Serial request query
Trig
waiting for triggering signal
OFF
Power supply in off mode
Timer
none
CW
Power supply in CP mode
-
-
