Saving method:
Press
+
Recall
(save) button, and then input the group number you want
to save through number key board. Press enter button to confirm. If you want to
recall the saved parameters, press
Recall
button and corresponding group
number (number1-9).At last press enter button to confirm.
3.8 Trigger Operation
You need to select the trigger mode from the menu before using this function.
After you edit a list file, press
+
Enter
(Trigger) to give a trigger signal.
During the running process,
Enter
button will be lit all the time.
3.9 Menu Operation
Press +
I-
set
I-
set
(Menu) to enter the menu. You will see a optional items on
the screen, through direction keys and rotary knob to upturn VFD display, then
the screen will display the following functions .Press
Enter
button will enter
corresponding items. Press
ESC
button will return to previous menu.
IT6922A/IT6932A/IT6933A/IT6942A/IT6952A/IT6953A power supply menu
function is shown as below.
MAX VOLT
Set the max output voltage
OCP SET OFF Disable the over current protection function.
ON Enable the over current protection function.
SYST SET
P-MEN (RESET)
Reset
Power is restored to factory setting
Keep
Set the power-on state as the last power off state
P-OUT (OFF)
OFF
Enable the power-on output state to be off mode
Keep
Set the power-on output state to be the
last
power-off output state
COMM (GPIB)
GPIB(IT6900(G)
series only)
ADDR Address can be set within 0-30
RS232
BAUD
4800
9600
19200
38400
57600
115200
NONE 8BIT
NONE 8BIT
EVEN 8BIT
ODD 8BIT
MODE
SIGNAL
