User Guide
2.1 Installation Process
This checklist can be used as a guideline for some of the necessary considerations that must be remembered
whenever installing and turning on an intersection using the Vantage video detection system. This is by no
means intended to be a detailed and all inclusive list. All of these areas and topics will be covered in great
detail in the following sections of this document.
a. Correct Interface and Power Cable
• IMSA 39-2/40-2 cable
• Power cable = 3 conductor, 16awg, stranded wire
b. Surge Protection – Installed and properly grounded
c. Camera Installation
• Mount the camera bracket, attach camera
• Electrical connections (Power and Video) properly made
• Sun shield adjusted - Pulled out (Extended)
• Camera tilted slightly downward
d. ICC Installation
• Switches properly set
• Plug the ICC Module into the appropriate slot of the detector rack or input file.
• Connect the monitor and mouse to the ICC Module.
• Press and hold the ICC Module "Menu" button in for approximately one second and then
release it. This will bring up the VersiCam main menu.
e. Camera Field of View (FOV)
• No Horizon in FOV
• Minimum 4 lane width
• Stop bar area in lower 1/3 of FOV
• Car bumpers parallel to bottom of screen
• Adequate area left for advanced detection
You never want the horizon to be included as part of your camera field of view. If the horizon is visible as part
of your field of view on East and West approaches, the camera maybe blinded by the sun at sunrise and
sunset. The camera should be rotated so that the bumpers of the vehicles are parallel with the bottom of the
screen.
