Devices to control this product, such as PLC
③ Control devices
② MDR
④ Safety relay
⑥MDR extension cables
（Option）
⑤Wiring materials
Necessary for wiring of power and signal
cables, branch connectors, driver cards,
controllers, such as sensors or PLCs,
and power supply.
Necessary when the
installing location of the
MDR is far from that
of the driver card.
〈Available wire diameter for driver card connectors〉
Power connector
Connector CBV30
Control connector
0.5〜1.5m㎡（AWG：20〜14）
0.08〜0.5m㎡（AWG：28〜20）
■
Cables can be extended up to 3000 mm, including the MDR cable length.
■
Do not extend cables by connecting multiple extension cables.
■
To select the current capacity of wiring materials, secure a high safety margin based
on the current value in the equipment to be used.
■
Longer wiring between the power supply unit and driver cards/controllers could
cause the voltage to decrease, resulting in malfunction and/or damage.
Model
ACE-CBL-K0600
ACE-CBL-K1200
L=

600mm
L=1200mm
ACE-CBL-K2700 L=2700mm
■
6-pin D shaped connector extension cable
6-pin D shaped connector extension cable
Safety precautions
Advance preparation
Check ProductInstallation/Wiring
Maintenance/Inspection
Specifications Control/Operation
4. Advance preparation
Theotherdevicesneedtobeprepared
CBV30UserManual
1
5
2
6
4
3
1
6
3
5
4
2
