ITOH DENKI CBV30 - Checking Appearance; Checking Accessories

17
Checking the model
Unpack the product, and check that the product model is what you ordered.
Checking appearance
Check any abnormalities, such as traces of scratches, dents, dirt, and/or corrosion
(rust) on MDR.
Checking accessories
Check that all the following items are included.
＊If any abnormalities are found, contact the supplier immediately.
（ for mounting the driver card
）
M4cross-recessedheadSWscrew×15/
M4hex.nut
Power connector
WAGO734-102
Control connector
WAGO733-103
1 p
2 sets
1 p
Safety precautions
Advance preparation
Check ProductInstallation/Wiring
Maintenance/Inspection
Specifications Control/Operation
5. Check Product
Checking the model
CBV30UserManual
CBV30ｰULｰN
Input and output signals
・N… NPN input and output signals
・P …PNP input and output signals
