ITOH DENKI CBV30 - Product Specifications

28
Product specifications
Specifications
Safety precautions
Advance preparation
Check ProductInstallation/Wiring
Maintenance/Inspection
Specifications Control/Operation
CBV30UserManual
Nominal speed
Product specifications
0 to 40ºC (no freezing)
90%RH or less (no condensation)
No corrosive gas
1.0G or less
Indoor
20msec or less
Time from RUN signal input

to
motor starting
WAGO734-102
Wire diameter: 0.8 to 1.5 mm
2
Driver card unit : 95ºC
Motor : 110ºC
WAGO733-103
Wire diameter: 0.08 to 0.5 mm
2
（
CN1
）
（
CN2
）
Wire
diameter
Power connector
Control connector
Thermal protection
IP20
Power supply voltage
Rated voltage
Static current
Starting current
CBV30Model
24V DC
±
10%
24V DC
0.05A
2.6A
±
0.2A
Peak current
20A
（
1msec
）
Ambient temperature
Ambient humidity
Atmosphere
Vibration
Location
Degree of protection
Operating
environment
Servo brake tangential force
PM380VS
60
17
60
17
57
173
51
154
PM427VS
tangential force
(N)
